Product Code:G24F-2
Features:
The last mile for your gaming system
As an unseen player, monitor is often being underestimated. The truth is monitors form as a synergistic effect and bring out the best performance of PC components. GIGABYTE gaming monitors offer the ultimate specifications and quality, users can truly enjoy upscale performance without the need for extravagance.
1ms MPRT Response Time
Super fast 1ms response time for the most smooth gaming experience ever!
FHD with 165Hz (OC 180Hz)
High resolution and fast refresh rate, giving you the detailed display quality and fluid gaming experience!
95% DCI-P3
Fantastic color display and 95% DCI-P3 super wide-gamut color.
Simple but stylish
The streamline appearance represents the simplicity of the GIGABYTE gaming series design philosophy, sturdy stand and matte finish built for functional and aesthetic features adding more to the characteristics.
OSD Sidekick
GIGABYTE OSD Sidekick allows you to set the display options with keyboard and mouse, giving you the easiest way to adjust monitor settings.
Alignment
The display alignment function will facilitate you on the multi-display set-up, monitors will line up perfectly.
Counter
The gaming counter will help you calculate the time more easily.
Dashboard
The dashboard reveals your real-time hardware information including CPU voltages, clock speed, temperatures, etc. The best part is that it won’t be blocked by any games.
Black Equalizer
This feature allows you to have more details of the dark side without overexposing the bright side at the same time.
Auto-Update
Users can effortlessly enjoy the finest gaming experience with features GIGABYTE continues to develop and upgrade while giving extra protection to your monitor.
Specifications:
| Panel Size (diagonal) |
23.8”SS IPS |
| Display Viewing Area (HxV) |
527.04x296.46 mm |
| Panel Backlight/ Type |
Edge |
| Display Surface(non-glare/ glare) |
Non-glare |
| Color Saturation |
95% DCI-P3, 125% sRGB |
| True Resolution |
1920 x 1080(FHD) |
| Pixel Pitch |
0.2745(H) x 0.2745(V) mm |
| Brightness |
300 cd/m2(TYP) |
| Contrast Ratio |
1100:1 |
| Viewing Angle |
178°(H)/178°(V) |
| Display Colors |
16.7M |
| Response Time |
1ms MPRT |
| Refresh Rate |
165Hz/OC 180Hz |
| HDR |
HDR ready |
| Flicker-free |
Yes |
| HBR3 |
No |
| Connectivity |
2 x HDMI 2.0
1 x Displayport 1.2 (capable for HDR)
2 x USB 3.2 Gen 1 Downstream ports
1 x USB 3.2 Gen 1 Upstream port
1 x Earphone Jack |
| Speaker |
N/A |
| Unique Features |
OSD Sidekick
Aim Stabilizer
Black Equalizer
Dashboard
Crosshair
Timer
Counter
Auto-Update
Smart OD |
| Power Type |
Power Board Build-in |
| Power Consumption |
17.5W |
| Power Saving Mode |
0.5W |
| Power Off Mode |
0.3W |
| Voltage |
100~240Vac |
| Tilt(angle) |
-5°~+20° |
| Swivel(angle) |
N/A |
| Pivot(angle/direction) |
N/A |
| Height Adjustment (mm) |
130 mm |
| VESA Wall Mounting(mm) |
100*100 mm |
| Kensington lock |
Yes |
| Phys. Dimension with Stand(WxHxD) |
541*519.3*136.75 mm |
| Phys. Dimension w/o stand (WxHxD) |
541*326.4*53.4 mm |
| Net Weight with stand (Esti.) |
4.8 kg |
| Net Weight without stand (Esti.) |
3.2 kg |
| Gross Weight (Esti.) |
7.83 kg |
| Special Note |
The test condition follows CEC standards.
To enable OSD Sidekick, it requires connection between PC and monitor with USB (A-Male to B-Male) cable. |
| Warranty |
3 Years |
| Note |
Features, Price, Specifications are subject to change without notice. Images used for representation purpose only |
