Product Code:NX416L-WHITE
Features:
Unique Design & Powerful Heat Dissipation
The NX416L features a unique design and excellent cooling performance. The mesh around the case and the fans on the PSU shroud create the possibility for a better heat dissipation of the graphics card. 11 x 120mm fans can be installed simultaneously.
High-Airflow mesh front panel with 2 pre-installed 160mm ARGB Fans
2 pre-installed 160mm ARGB fans and the vast of mesh ensure massive airflow and maximum cooling performance without giving into dust prevention.
Swing-Opening Tempered Glass Side Panel
The swing-opening left panel made of tempered glass makes interior components easy to access, more convenient for installation and cleaning.
Powerful Cooling
Install a 240mm radiator with decorative storage panel removed.
Optimized Storage Panel
Install two 2.5" SSD in the decorative panel beside the MB area.
Pre-Installed 3 ARGB fans
Build-in LED & PWM Fan Controller
The built-in control hub can sync with the motherboard or switch the ARGB lighting modes with the ARGB control button for your personalized setup.
I/O Panel
Power, LED Control Button, 1 x USB 3.0, Headphone/Mic Combo Jack, Type-C
Neat Build within Reach
24mm space for cable management ensures your PC build looks neat.
Unlimited Performance Max. GPU Length:
≤ 415mm (without front fan)
≤ 390mm (with front fan)
≤ 280mm (when radiator is installed on the side)
Specifications:
| Model Number |
NX416L-WHITE |
| Dimensions |
471 x 210 x 486mm(DWH)
471 x 218 x 486mm(DWH)(With handle) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic + Glass |
| Mainboard Support |
ATX, M-ATX, ITX |
| Front Access & Controls |
Power, LED Control Button, 1 x USB 3.0 , 1 x Type C , Headphone/Mic Combo Jack |
| Side Panel |
Tempered Glass Side Panel |
| Drive Bays |
| Expansion Slots |
7 |
| 3.5" /2.5" |
2/2 |
| 2.5" |
3 |
| Fan Support |
| Front |
3 x 120mm / 3 x 140mm / 2 x 160mm Antec Custom Fan |
| Top |
3 x 120mm / 2 x 140mm |
| Side |
2 x120mm |
| Power Supply Shroud |
2 x120mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
2 x 160mm ARGB fans in front + 1 x 120mm ARGB fan in rear |
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360mm |
| Side |
120 / 240mm |
| Top |
120 / 140 / 240 / 280 / 360mm |
| Rear |
120mm |
| Clearance |
| Max GPU Length |
≤ 280mm (when radiator is installed on the side)
≤ 390mm (with front fan)
≤ 415mm (without front fan) |
| Max CPU Cooler Height |
≤ 165mm |
| Max PSU Length |
(Include cable)≤ 240mm |
| Miscellaneous |
| Dust Filter |
Top / Bottom / Right Side |
| Net Weight |
6.4 Kg |
| Gross Weight |
7.5 Kg
|
| Warranty |
1 Year |
| Note |
*** Features, Price, Specifications are subject to change without notice.
| Cabinet Size |
MID-TOWER |
| Color |
White |
| Material |
Steel, Plastic, Tempered Glass |
| Expansion Slots |
7 |
| Motherboard Size |
ATX, M-ATX, ITX |
| Max CPU Cooler Height |
165mm |
| Max PSU Length |
240mm |
| Max Gpu Length |
415mm |
| Max 3.5" HDD |
2 |
| Max 2.5" SSD |
3 |
| Dust Filters |
Top, Bottom, Side |
| Pre Installed Fans |
3 |
| Max Fan Support |
11 |
| Radiator Support |
360mm,280mm,240mm,140mm,120mm |
| Front I/O Panel |
Power, LED Control Button, USB 3.0, Headphone/Mic Combo Jack, Type-C |
| Warranty |
1 Year |
| Note*** |
Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only.
|
|
